SMD WATCH CRYSTAL 6.9 x 1.4 mm 32.768 kHz
- High reliability for low cost
- Low profile – 1.4 mm max. package height
- Operating temperature range of -40/+85°C
- Excellent clock signal generator for CPU´s
-
Product Name
32.768 kHz Quartz Crystal
-
Package
Plastic SMD
-
Dimensions in mm (W x D x H)
6.9 x 1.4 x 1.4 mm
-
Frequency Range
32.768 kHz
-
NUMBER OF SOLDER PADS
2
-
FREQUENCY TOLERANCES AT 25°C
±20 ppm (standard)
-
LOAD CAPACITANCE (CL)
12.5 pF (standard)
7pF and 9pF available on request -
WORKING TEMPERATURE RANGE
-40/+85°C
-
RESONANCE RESISTANCE
65 kΩ max.
-
SHUNT CAPACITANCE C0
0.8 pF typ.
-
TURNOVER TEMPERATURE
+25°C ±5°C
-
PARABOLIC COEFFICIENT
-0.04 ppm/°C²
-
DRIVE LEVEL
1.0 µW max.
-
AGING
±3 ppm max. per year
-
INSULATION RESISTANCE
>500 MΩ DC/100V ±10%
-
STORAGE TEMPERATURE
-55°/+125°C
-
DELIVERY FORM
Tape and Reel (1.000 pcs per reel)
DATASHEET: SMD 32.768 kHz QUARTZ CRYSTAL M6714
