For Bluetooth applications, PETERMANN-TECHNIK offers low cost SMD crystals in a 2.0x1.6mm package with low resistance for fast transient response. The micro SMD crystals available in the frequency range of 24 - 60 MHz can be supplied with frequency tolerances at +25°C >±10ppm, or with temperature stabilities of ±8ppm@0/+50°C, ±10ppm@-20/+70°C or >±15ppm@-40/+85°Crespectively. The ageing is ±2ppm max. after the first year, or ±10ppm after 10 years and can therefore be used very well in all wireless applications, such as Bluetooth, WLAN, ISM band up to 915 MHz, IoT, KNX, ZigBee, Sigfox, LoRa, wearables, etc. Drive levels of up to 200µW can be realised on request. PETERMANN-TECHNIK's very extensive range of services also includes 32,768 kHz solutions (SMD crystals and SMD ultra low power oscillators), in-depth product advice and very comprehensive engineering services for fast and reliable integration of the crystals into the corresponding customer circuits.
Further information can be found at:
SMD oscillating crystal 2.0x1.6mm
Technical questions:
Telephone: 0 81 91 / 30 53 95
E-mail: info(at)petermann-technik.de
