PETERMANN-TECHNIK offers several frequency-generating components directly from stock, which can be shipped with short delivery times. These include SMD crystals for 32.768 kHz in miniature packages such as 3.2x1.5 mm, 2.0x1.2 mm and 1.6x1.0 mm. SMD crystals for MHz frequencies are also available in numerous standard designs from 1.6x1.2 mm to 7.0x5.0 mm. SMD quartz oscillators for MHz frequencies and 32.768 kHz are also available from stock in several package sizes. The stock range is therefore suitable for compact designs as well as for industrial and specification-based applications.

The range available from stock includes a wide selection of SMD quartz housings for different design requirements. The 32,768 kHz crystals are available in formats including 3.2x1.5 mm, 2.0x1.2 mm and 1.6x1.0 mm, each with 2 pads. For MHz crystals, designs such as 1.6x1.2 mm, 2.0x1.6 mm, 2.5x2.0 mm, 3.2x2.5 mm, 5.0x3.2 mm, 6.0x3.5 mm and 7.0x5.0 mm are also available. Depending on the housing, there are variants with 2 pads or 4 pads, allowing the components to be flexibly integrated into existing layouts. This variety facilitates the selection of suitable crystals for space-critical, industrial and automotive-oriented applications.

The 32,768 kHz SMD crystals available from stock are designed for precise time base applications with a frequency of 32,768 kHz. According to the page content, these variants are available with a frequency tolerance of ±20 ppm and for a temperature range of -40 to +85 °C. Depending on the housing, different load capacities are available, including 6.0 pF, 7.0 pF, 9.0 pF and 12.5 pF. This allows developers to tailor the right version to the requirements of their circuit. Especially for RTC, IoT and battery-powered applications, these stocked crystals are a practical solution with short delivery times.

Yes, the stock program also includes products that are suitable for demanding industrial operating conditions. In the case of SMD crystals for MHz frequencies, it is expressly stated that automotive versions are also available according to specification. The SMD quartz oscillators listed also cover supply voltages from 1.8 to 3.3 VDC and accuracies from ±25 ppm to ±100 ppm. Depending on the version, temperature ranges of up to -40 to +125 °C are specified, which is relevant for many industrial and extended application environments. This means that robust designs with short procurement times can also be realized.

PETERMANN-TECHNIK combines a stocked product range with a simple and fast communication option. Interested parties can select the relevant product link and use the appropriate product or sample enquiry form directly. In addition, contact options are available by telephone, e-mail and callback service. This makes it easier to coordinate requirements and plan reliable delivery dates. This direct inquiry processing is an important advantage, especially for development projects and series requirements.

PETERMANN-TECHNIK is a strong choice when quartz crystals and oscillators need to be available at short notice and a wide technical selection is required at the same time. The stock program includes 32.768 kHz SMD crystals as well as MHz crystals and SMD crystal oscillators in many common housing sizes. Even demanding requirements such as different load capacities, industrial temperature ranges or automotive versions according to specification are taken into account. The short delivery times and direct contact via product links, inquiry forms, telephone or e-mail make procurement much easier. This provides B2B customers with a reliable combination of technical accuracy, fast availability and predictable delivery dates.
