NAME:SMD0503/4 (Low ESR)

IMAGE:1

SMD QUARTZ CRYSTAL 5.0 x 3.2 mm 8.0 - 80.0 MHz

SMD QUARTZ CRYSTAL 5.0 x 3.2 mm 8.0 - 133.0 MHz

  • Frequency tolerances of ±10ppm@+25°C, tight temperature stabilities and low aging deliverable
  • High reliability for low cost
  • Low resistance quartz design (LRT technology) for fast and safe oscillation start-up
  • Extended temperature range to -40/+125°C available
  • Qualified for automotive applications
  • Excellent clock signal generator for CPU´s
  • Product Name

    SMD Quartz Crystal

  • Package

    SMD Ceramic/4pad

  • Dimensions in mm (W x D x H)

    5.0 x 3.2 x 0.8 mm

  • Frequency Range

    8.00 - 133.00 MHz

  • NUMBER OF SOLDER PADS

    4

  • FREQUENCY RANGES (SEPARATED)

    8.0 ~ 54.0 MHz Fundamental
    54.0 ~ 133.0 MHz 3rd Overtone

  • STANDARD FREQUENCIES

    8.192 MHz / 13.56 MHz / 14.318 MHz / 14.7456 MHz / 15.36 MHz / 16.0 MHz / 19.2 MHz / 19.66 MHz / 20.0 MHz / 22.5792 MHz / 24.0 MHz / 25.0 MHz / 26.0 MHz / 27.0 MHz / 27.12 MHz / 29.4912 MHz / 32.0 MHz / 36.0 MHz / 40.0 MHz / 48.0 MHz / 50.0 MHz

  • FREQUENCY TOLERANCES AT 25°C

    ±8 ppm ~ ±50 ppm

  • LOAD CAPACITANCE (CL)

    6 pF ~ 50 pF or Series

  • WORKING TEMPERATURE RANGES

    0/+50°C ~ -40/+125°C

  • SHUNT CAPACITANCE C0

    3 pF max.

  • DRIVE LEVEL Fundamental

    100 μW typ. / 200 μW max. (300 μW available on request)

  • DRIVE LEVEL 3rd Overtone

    100 μW typ. / 200 μW max. (300 μW available on request)

  • AGING

    ±2 ppm per year standard (±1 ppm available as option)

  • INSULATION RESISTANCE

    >500 MΩ DC/100V ±10%

  • STORAGE TEMPERATURE

    -55°+125°C

  • DELIVERY FORM

    Tape and Reel (1.000 pcs per reel)

  ±5 ppm ±10 ppm ±15 ppm ±20 ppm ±30 ppm ±50 ppm
0/50 °C
-10/60 °C
0/70 °C
-20/70 °C
-40/85 °C
-40/105 °C
-40/125 °C
SMD QUARTZ CRYSTAL 8.0 - 80.0 MHz

DATASHEET: SMD QUARTZ CRYSTAL SMD0503-4

SMD QUARTZ CRYSTAL SMD0503-4
