Frequency control products

FREQUENCY CONTROL TOP SELLER PRODUCTS RECOMMENDED FOR NEW DESIGNS

With us you will find the currently widest and deepest product range for frequency-generating components on the market.

So, that you can quickly receive information about the TOP SELLER products recommended for new developments, you will find our product recommendations summarized in this list. You can use our TOP SELLER products in all applications, including automotive applications (AECQ100 or AECQ200), where extremely reliable components with an excellent price-performance ratio have to be used.

In addition, our TOP SELLER products are characterized by their excellent performance in combination with outstanding quality and longevity.

There is no EOL for the TOP SELLER products we recommend, as well as for our entire range of available products. So you can safely integrate our quartz crystals, oscillators, ceramic resonators, etc. in your applications and purchase them over a very long time.

You can use the product generator that you will find for each product to configure your desired product and request it with a click or communicate with us.

If you have questions about our products, call us under the number:  + 49/(0) 8191/305395, or arrange a callback with us. One of our specialists will contact you.

Customer satisfaction is at the focus of our thinking and acting.

Top Seller SMD Quartz Crystals

  Product Name Package Product Category Dimensions in mm (W x D x H) Frequency Range Data Sheet Product
SMD02016/4 (Low ESR)
SMD02016/4 (Low ESR) SMD Ceramic/4pad MHz Crystal 2.0 x 1.6 x 0.45 mm 16.00 - 285.00 MHz PDF Enquiry
SMD03025/4 (Low ESR)
SMD03025/4 (Low ESR) SMD Ceramic/4pad MHz Crystal 3.2 x 2.5 x 0.8 mm 8.00 - 285.00 MHz PDF Enquiry
SMD03025/4 Ultrasonic
SMD03025/4 Ultrasonic SMD Ceramic/4pad MHz Crystal 3.2 x 2.5 x 0.7 mm 12.00 - 40.00 MHz PDF Enquiry
SMD0503/4 (Low ESR)
SMD0503/4 (Low ESR) SMD Ceramic/4pad MHz Crystal 5.0 x 3.2 x 0.8 mm 8.00 - 133.00 MHz PDF Enquiry
M1610 (AVAILABLE IN STOCK)
M1610 (AVAILABLE IN STOCK) SMD Ceramic/2pad kHz Crystal 1.6 x 1.0 x 0.45 mm 32.768 kHz PDF Enquiry
M3215 (AVAILABLE IN STOCK)
M3215 (AVAILABLE IN STOCK) SMD Ceramic/2pad kHz Crystal 3.2 x 1.5 x 0.75 mm 32.768 kHz PDF Enquiry
M3215HT (High Temp. -40/+125°C)
M3215HT (High Temp. -40/+125°C) SMD Ceramic/2pad kHz Crystal 3.2 x 1.5 x 0.75 mm 32.768 kHz PDF Enquiry
M3215RR (50 kΩ - low power design)
M3215RR (50 kΩ - low power design) SMD Ceramic/2pad kHz Crystal 3.2 x 1.5 x 0.75 mm 32.768 kHz PDF Enquiry

Top Seller Quartz Crystal Osillators

  Product Name Package Dimensions in mm (W x D x H) Frequency Range Data Sheet Product
SPXO
SPXO SMD Ceramic/4pad 2.5 x 2.0 x 1.0 mm 0.20 - 167.00 MHz PDF Enquiry
SPXO
SPXO SMD Ceramic/4pad 3.2 x 2.5 x 1.2 mm 0.20 - 167.00 MHz PDF Enquiry
TCXO
TCXO SMD Ceramic/4pad 2.0 x 1.6 x 0.6 mm 13.00 - 52.00 MHz PDF Enquiry
TCXO
TCXO SMD Ceramic/4pad 2.5 x 2.0 x 0.8 mm 9.60 - 52.00 MHz PDF Enquiry
VCTCXO
VCTCXO SMD Ceramic/4pad 2.0 x 1.6 x 0.6 mm 13.00 - 52.00 MHz PDF Enquiry
VCTCXO
VCTCXO SMD Ceramic/4pad 2.5 x 2.0 x 0.8 mm 9.60 - 52.00 MHz PDF Enquiry

Top Seller Silicon Oscillators

Top Seller ULTRA LOW POWER 32.768 KHZ

  Product Name Package Dimensions in mm (W x D x H) Frequency Range Supply Voltage Output Signal Data Sheet Product
ULPO-RB1
ULPO-RB1 SMD QFN/4pad 1.5 x 0.8 32.768 kHz 1.2 - 3.63 VDC LVCMOS PDF Enquiry
ULPO-RB2
ULPO-RB2 SMD QFN/4pad 2.0 x 1.2 32.768 kHz 1.2 - 3.63 VDC LVCMOS PDF Enquiry

Top Seller LOW POWER 1 - 137 MHZ

  Product Name Package Dimensions in mm (W x D x H) Frequency Range Supply Voltage Output Signal Data Sheet Product
LPO
LPO SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 1.00 - 110.00 MHz 1.8 ~ 3.63 VDC LVCMOS/HCMOS compatible output PDF Enquiry
LPO
LPO SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 115.20 - 137.00 MHz 1.8 ~ 3.63 VDC LVCMOS/HCMOS compatible output PDF Enquiry

Top Seller HIGH-TEMPERATURE 1 - 137 MHZ

  Product Name Package Dimensions in mm (W x D x H) Frequency Range Supply Voltage Output Signal Data Sheet Product
HTLPO
HTLPO SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 1.00 - 110.00 MHz 1.8 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
HTLPO
HTLPO SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 115.20 - 137.00 MHz 1.8 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
WTLPO
WTLPO SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 1.00 - 110.00 MHz 1.8 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
WTLPO
WTLPO SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 119.34 - 137.00 MHz 1.8 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry

Top Seller Differential 1 - 625 MHz

  Product Name Package Dimensions in mm (W x D x H) Frequency Range Supply Voltage Output Signal Data Sheet Product
DLPO-3
DLPO-3 SMD QFN/6pad 3.2 x 2.5 ~ 7.0 x 5.0 1.00 - 220.00 MHz 2.25 ~ 3.63 VDC LVPECL and LVDS output types PDF Enquiry
DLPO-4
DLPO-4 SMD QFN/6pad 3.2 x 2.5 ~ 7.0 x 5.0 220.00 - 625.00 MHz 2.25 ~ 3.63 VDC LVPECL and LVDS output types PDF Enquiry

Top Seller AUTOMOTIVE HIGH-TEMPERATURE 1 - 137 MHZ

  Product Name Package Dimensions in mm (W x D x H) Frequency Range Supply Voltage Output Signal Data Sheet Product
LPO-AUT
LPO-AUT SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 1.00 - 110.00 MHz 1.62 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
LPO-AUT
LPO-AUT SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 115.20 - 137.00 MHz 1.62 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
HTLPO-AUT
HTLPO-AUT SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 1.00 - 110.00 MHz 1.62 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
HTLPO-AUT
HTLPO-AUT SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 115.20 - 137.00 MHz 1.62 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
WTLPO-AUT
WTLPO-AUT SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 1.00 - 110.00 MHz 1.62 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
WTLPO-AUT
WTLPO-AUT SMD QFN/4pad 2.0 x 1.6 ~ 7.0 x 5.0 115.20 - 137.00 MHz 1.62 ~ 3.63 VDC LVCMOS/LVTTL compatible output PDF Enquiry
