Find PETERMANN-TECHNIK Quartz Crystals based on parametric data entry. Use this configurator providing pull-down menus for selecting your crystal.
Entering more parameters will narrow search results. Compare, Select & Evaluate!
For further information and support please use our contact-forms or contact our specialized engineering team under the following phone number: +49/8191/305395.
Each quartz oscillator has its own product generator, with which you can configure your desired product and request it quickly and easily with one click.
HC-49/US-SMD - if there is a lot of space on the board. Low resistances allow fast oscillation start-up.
SMD02016/4 - resistance-optimized, very fast oscillating MICRO-SMD quartz crystal for very small applications, also suitable for automotive.
SMD03025/4 - the most universal and cost-effective MINI-SMD quartz in the ceramic housing. Low resistances promote fast oscillation start-up.
SMD0503/4 - cheapest SMD crystal for the frequency range 8.0 - 12.0 MHz, also suitable for automotive. For > 12 MHz is recommended SMD03025/4.
M2012 - very small 32.768 kHz low resistance quartz crystal.
M3215 - is the most used 32.768 kHz SMD watch quartz. Also available as a reduced resistance version with 50 kOhm max. for low power designs und automotive applications (AECQ200).
| Product Name | Dimensions in mm (W x D x H) | Center Frequency (MHz) | Bandwidth (MHz) | In/Out Impedance (Ohm) | Input Power (W) | Insertion Loss (dB) | Attenuation (dB) | Temperature Range | Data Sheet | |
|---|---|---|---|---|---|---|---|---|---|---|
|
DTCVCTO | 3.2 x 2.5 ~ 7.0 x 5.0 | 0.0 - 0.0 | 0.0 - 0.0 | 0.0 - 0.0 | 0.0 - 0.0 | 0.0 - 0.0 | 0.0 - 0.0 | 0/70°C ~ -40/85°C |
|
With just a few clicks, you can immediately request samples for every required product
