Our reference list shows you which ICs, among others, our quartz crystals can be used with. Of course, for the clocking of other ICs corresponding crystals - with very low resistance for exceptionally fast and safe oscillation - from our extremly wide and deep product range available. For new developments we suggest MHz quartz series SMD03025/4 (3.2x2.5mm/4pad) or SMD2016/4 (2.0x1.6/4mm). The SMD03025/4 series SMD crystal is currently the cheapest miniaturised SMD quartz, or the SMD02016/4 series SMD crystal is used in applications where the SMD03025/4 is too large. Additionally, if you require SMD quartz crystals for ultrasonic, we recommend the following product housings: SMD02016/4US and SMD03025/4US.

Manufacturer IC Package Frequency CL ESR Product Number Data Sheet Sample Product
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1261 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1261 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1262 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1262 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1268 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1268 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1272 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1272 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1276 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1276 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1231 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1231 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1231H 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1231H 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R
PDF
Request Enquiry
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 8 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R
PDF
Request Enquiry
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R
PDF
Request Enquiry
Semtech SX1232 2.0 x 1.6 mm 32.000 MHz 10 pF 40 Ω SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R
PDF
Request Enquiry
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 8 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 8 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 10 pF 25 Ω SMD03025/4 32.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1232 3.2 x 2.5 mm 32.000 MHz 10 pF 30 Ω SMD03025/4 32.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/50/-40+125/10pF/AUT
PDF
Request Enquiry
Semtech SX1280 2.0 x 1.6 mm 52.000 MHz 10 pF 50 Ω SMD02016/4 52.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/50/-40+125/10pF/AUT
PDF
Request Enquiry
Semtech SX1280 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/15/-40+85/10pF
PDF
Request Enquiry
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/10/-20+70/10pF
PDF
Request Enquiry
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/50/-40+125/10pF/AUT
PDF
Request Enquiry
Semtech SX1281 3.2 x 2.5 mm 52.000 MHz 10 pF 25 Ω SMD03025/4 52.000 MHz 10/20/-40+85/10pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 8 pF 30 Ω SMD02016/4 50.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 12 pF 30 Ω SMD02016/4 50.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 8 pF 30 Ω SMD02016/4 50.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 50.000 MHz 8 pF 30 Ω SMD02016/4 50.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 8 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 24.000 MHz 12 pF 60 Ω SMD02016/4 24.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 12 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 48.000 MHz 8 pF 40 Ω SMD02016/4 48.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 8 pF 30 Ω SMD03025/4 24.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 12 pF 30 Ω SMD03025/4 24.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 8 pF 30 Ω SMD03025/4 24.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 24.000 MHz 8 pF 30 Ω SMD03025/4 24.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 25.000 MHz 8 pF 30 Ω SMD03025/4 25.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 25.000 MHz 8 pF 30 Ω SMD03025/4 25.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 12 pF 25 Ω SMD03025/4 50.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 8 pF 25 Ω SMD03025/4 50.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 8 pF 25 Ω SMD03025/4 50.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 50.000 MHz 8 pF 25 Ω SMD03025/4 50.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 8 pF 30 Ω SMD03025/4 26.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 8 pF 30 Ω SMD03025/4 26.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 12 pF 30 Ω SMD03025/4 26.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 8 pF 30 Ω SMD03025/4 26.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 26.000 MHz 12 pF 30 Ω SMD03025/4 26.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 12 pF 25 Ω SMD03025/4 48.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 8 pF 25 Ω SMD03025/4 48.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 12 pF 25 Ω SMD03025/4 48.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM SPIRIT1 3.2 x 2.5 mm 48.000 MHz 12 pF 25 Ω SMD03025/4 48.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 8 pF 50 Ω SMD02016/4 25.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 25.000 MHz 12 pF 50 Ω SMD02016/4 25.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
STM STM8AF/AL/S 5.0 x 3.2 mm 8.000 MHz 12 pF 150 Ω SMD0503/4 8.000 MHz 10/10/-20-70/12pF/150R/500µW
PDF
Request Enquiry
STM STM8AF/AL/S 5.0 x 3.2 mm 8.000 MHz 12 pF 150 Ω SMD0503/4 8.000 MHz 10/15/-40-85/12pF/150R/500µW
PDF
Request Enquiry
STM STM8AF/AL/S 5.0 x 3.2 mm 8.000 MHz 12 pF 150 Ω SMD0503/4 8.000 MHz 10/20/-40-85/12pF/150R/500µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 400 Ω SMD03025/4 8.000 MHz 10/10/-20-70/12pF/400R/200µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 500 Ω SMD03025/4 8.000 MHz 10/10/-20-70/12pF/500R/500µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 400 Ω SMD03025/4 8.000 MHz 10/20/-40-85/12pF/400R/200µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 500 Ω SMD03025/4 8.000 MHz 10/15/-40-85/12pF/500R/500µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 400 Ω SMD03025/4 8.000 MHz 10/15/-40-85/12pF/400R/200µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 8.000 MHz 12 pF 500 Ω SMD03025/4 8.000 MHz 10/20/-40-85/12pF/500R/500µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 16.000 MHz 12 pF 300 Ω SMD03025/4 16.000 MHz 10/10/-20-70/12pF/50R/300µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 16.000 MHz 12 pF 300 Ω SMD03025/4 16.000 MHz 10/15/-40-85/12pF/50R/300µW
PDF
Request Enquiry
STM STM8AF/AL/S 3.2 x 2.5 mm 16.000 MHz 12 pF 300 Ω SMD03025/4 16.000 MHz 10/20/-40-85/12pF/50R/300µW
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 8 pF 25 Ω SMD02016/4 50.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 12 pF 25 Ω SMD02016/4 50.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 8 pF 25 Ω SMD02016/4 50.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 50.000 MHz 8 pF 25 Ω SMD02016/4 50.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/10/-20+70/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/15/-40+85/12pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 8 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/8pF
PDF
Request Enquiry
STM S2-LP (SPIRIT-2) 2.0 x 1.6 mm 26.000 MHz 12 pF 50 Ω SMD02016/4 26.000 MHz 10/20/-40+85/12pF
PDF
Request Enquiry
Diese Seiten auf deutsch
Call us

Write an Email

Just send us an Emai to:

info(at)petermann-technik.de

Call us

SAMPLE REQUEST

SMD Quartz Crystal 3.2 x 2.5 mm12.0 - 80.0 MHz

With just a few clicks, you can immediately request samples for every required product
