SMD VCXO OSCILLATOR 7.0 x 5.0 mm 1.0 - 170.0 MHz

SMD VCXO OSCILLATOR 7.0 x 5.0 mm 1.0 - 170.0 MHz

  • High reliability for low cost
  • 4pad and 6pad package designs
  • Wide frequency range / wide tuning range
  • High stability, low jitter, low power consumption
  • Extended operable temperature range -40°C to +85°C
  • Product Name

    VCXO

  • Package

    SMD Ceramic/4pad and 6pad

  • Dimensions in mm (W x D x H)

    7.0 x 5.0 x 1.8 mm

  • Frequency Range

    1.00 - 170.00 MHz

  • FREQUENCY RANGE VS SUPPLY VOLTAGE

    3.3 VDC = 1.0 - 40.0 MHz (4 Pads)
    5.0 VDC = 1.0 - 40.0 MHz (4 Pads)
    3.3 VDC = 1.0 - 170.0 MHz (6 Pads)
    5.0 VDC = 1.0 - 170.0 MHz (6 Pads)

  • FREQUENCY STABILITY

    ±20 ppm / ±25ppm / ±50 ppm

  • OPERATING TEMPERATURE RANGE

    -10/+70°C ~ -40/+85°C

  • STORAGE TEMPERATURE RANGE

    -55/+125°C

  • DELIVERY FORM

    TAPE & REEL

  • RoHS

    Lead free and RoHS 2 compliant

CERAMIC SMD VCXO OSCILLATOR 7.0 x 5.0 mm

DATASHEET: SMD VCXO 7.0x5.0 mm 4pad 3.3-5.0 VDC MHz

SMD VCXO 7.0x5.0mm 4pad 3.3-5.0 VDC MHz

DATASHEET: SMD VCXO 7.0x5.0 mm 6pad 3.3-5.0 VDC MHz

SMD VCXO 7.0x5.0mm 6pad 3.3-5.0 VDC MHz
